| Al2O3 (%,Min): | 75 | SiO2 (%,Max): | 20 |
|---|---|---|---|
| Bulk Density (g/cm3,Min): | 2.60 | C.C.S (MPa, Min): | 1100℃*3h Burned 80 |
| P.L.C (%): | 1100℃*3h Burned -0.1~0.3 | ||
| High Light: | boiler refractory material,castable refractory material |
||
Fiber Reinforced Castable Refractory refer to the refractory castables that can increase the strength after adding fibers to the refractory castables. Fiber Reinforced Castable Refractory can be divided into steel fiber reinforced refractory castables and alumina fiber reinforced refractory castables.
Steel Fiber Reinforced Castable Refractory is made of special bauxite clinker as aggregate, high quality bauxite clinker and corundum fine powder as matrix, ultrafine powder and other composite materials as binder and additive, plus stainless steel heat-resistant fiber, At the same time, due to the addition of steel fibers, the overall strength of the furnace wall after pouring the material is greatly enhanced.
Fiber Reinforced Castable Refractory Characters
1.high strength.
2.good toughness.
3.strong thermal shock resistance.
4.good spalling resistance, and it has been applied in the key parts of heat treatment furnaces, heating furnaces, soaking furnaces and other kiln furnaces and thermal equipment, and has obtained good technical and economic results.
Applications:
Steel Fiber Reinforced Castable Refractory is applicable to Masonry high temperature mechanical vibration, thermal shock, wear and other parts.
In the steel, metallurgy, chemical and building materials industries are widely used;In the CFB boiler, often used in furnace outlet and side wall, top, cyclone straight section, cyclone top, returner and other parts.
| Steel fiber Reinforced Castable Refractory |
Al2O3 (%,Min) |
SiO2 (%,Max) |
Bulk density (g/cm3,Min) |
C.C.S (MPa, Min) | P.L.C (%) |
Water content for construction (%) |
||
| 110℃*24h dry off | 1100℃*3h burned | 1100℃*3h burned | 1500℃*3h burned | |||||
| High-Al GF-15 | 75 | 20 | 2.60 | 80 | 80 | -0.1~0.3 | / | 6~7 |
| High-Al GF-16 | 78 | 15 | 2.65 | 100 | 100 | -0.1~0.3 | / | 5.5~6.5 |
| Corundum GF-17 | 90 | 6 | 3.00 | 100 | 100 | -0.1~0.3 | ±0.6 | 4.5~5.5 |
| Corundum GF-18S | 92 | 4 | 3.00 | 100 | 100 | -0.1~0.3 | ±0.6 | 5~6 |
| Remark | ISO Certificated; Customized | |||||||
| Application | CFB boiler, Cement rotary kiln mouth, cooler, pulverized coal burner and any other industrial kiln lining | |||||||
Q1: Is Jundao (Henan) New Materials a manufacturer or trader?
A1: Manufacturer, sometimes we help our clients to purchase relevant products as a trader.
Q2: What’s the MOQ?
A2. The MOQ is 25 tons.
Q3: Can we visit your factory?
A3: Of course ,welcome at any time,seeing is believing
Q4: What’s your payment terms?
A4: Negotiation
Q5: Is your company accept customization?
A5: Yes. Professional technology teams and engineers all can satisfy you.
Q6: How do you guarantee quality?
A6: For every production processing,we have complete QC system for the chemical composition and Physical properties.After production,all the goods will be tested ,and the quality certificate will be shipped along with goods.
Q7: Does your Jundao (Henan)?New Materials?supply samples?
A7: Yes, we can supply samples if necessary.
